WAGO Constant voltage supply 1 pc(s) 288-800 24 V AC
EAN:
Part number:
Item no:
Product type
Constant voltage supply
Connection
Spring-loaded terminal
Min. operating voltage
24 V AC
Max. operating voltage
24 V AC
Type
288-800
Datasheet (PDF)
Number
Total (€ 105.03 / piece)
€ 105.03
plus VAT.
Technical specifications
- Output voltage: 24 V/DC
- Rated output current 3 A
- Cross-section: 0.08 - 2.5 mm²
- AWG 28 - 12
- Stripping length: 5 - 6 mm
- Product type
Constant voltage supply
- Type
288-800
- Connection
Spring-loaded terminal
- Min. operating voltage
24 V AC
- Max. operating voltage
24 V AC
- Operating voltage
24 V AC
- Min. temperature
-25 °C
- Max. temperature
+40 °C
- Width
140 mm
- Height
44 mm
- Dim
(W x H) 140 mm x 44 mm
- Content
1 pc(s)
- Type
288-800
140
85 mm
44 mm
FALSE
FALSE
8
AC
Spring clamp connection
TRUE
IP20
Documents & Downloads
Datasheet
Datasheet 507064 WAGO Constant voltage supply 1 pc(s) 288-800 24 V AC
User & Safety Instructions
User & Safety Instructions 507064 WAGO Constant voltage supply 1 pc(s) 288-800 24 V AC
Description
With universal mounting base.
