WAGO DC-DC converter 1 pc(s) 859-804 8 - 16 V DC
EAN:
Part number:
Item no:
Product type
DC-DC converter
Connection
Spring-loaded terminal
Min. operating voltage
8 V DC
Max. operating voltage
16 V DC
Type
859-804
Datasheet (PDF)
Technical specifications
- Input Nominal voltage: 12 V/DC
- Output voltage: 24 V/DC
- Output current (max.): 250 mA
- Efficiency (type): 83%
- Delay: 8 ms
- Product type
DC-DC converter
- Type
859-804
- Connection
Spring-loaded terminal
- Min. operating voltage
8 V DC
- Max. operating voltage
16 V DC
- Operating voltage
8 - 16 V DC
- Min. temperature
-25 °C
- Max. temperature
+55 °C
- Width
6 mm
- Height
56 mm
- Length
91 mm
- Dim
(L x W x H) 91 x 6 x 56 mm
- Content
1 pc(s)
- Type
859-804
- Operating voltage
12 V
6
91 mm
91 mm
56 mm
TRUE
FALSE
0.33
DC
Spring clamp connection
TRUE
IP20
- UKCA
yes
