WAGO Feeder module 1 pc(s) 288-815 230 V AC
EAN:
Part number:
Item no:
Product type
Feeder module
Connection
Spring-loaded terminal
Min. operating voltage
230 V AC
Max. operating voltage
230 V AC
Type
288-815
Datasheet (PDF)
Number
Total (€ 226.05 / piece)
€ 226.05
plus VAT.
Technical specifications
- Nominal voltage: ± 15 V/DC
- Cross-section: 0.08 - 2.5 mm²
- AWG 28 - 12
- Stripping length: 5 - 6 mm
- Output (Ampere): 2 x 0.5 A
- Power consumption: 27 VA
- Frequency: 50 - 60 Hz
- Product type
Feeder module
- Type
288-815
- Connection
Spring-loaded terminal
- Min. operating voltage
230 V AC
- Max. operating voltage
230 V AC
- Operating voltage
230 V AC
- Min. temperature
0 °C
- Max. temperature
+40 °C
- Width
94 mm
- Height
57 mm
- Dim
(W x H) 94 mm x 57 mm
- Content
1 pc(s)
- Type
288-815
- Frequency
50 - 60 Hz
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 507169 WAGO Feeder module 1 pc(s) 288-815 230 V AC
User & Safety Instructions
User & Safety Instructions 507169 WAGO Feeder module 1 pc(s) 288-815 230 V AC
Description
With universal mounting socket, Output Voltage display.
