Weidmüller 1165940060 RJ45 Network cable, patch cable CAT 6A S/FTP 6.00 m Grey UL-approved 1 pc(s)
EAN:
Part number:
Item no:
Product type
Network cable, patch cable
Specification
CAT 6A
Shielding
S/FTP
Connection type
RJ45
Cable length
6.00 m
Datasheet (PDF)
Highlights & Details
Belkin CAT5e S/UTP Patch cable
- IE-C6FP8LD0060 M40 M40-D
Technical specifications
- Deviation 25 ns/100m
- Arrangement of wires: Twisted pair
- Number of wires: 8
- Operating voltage: 48 V AC/DC
- Operating voltage (UL rating): 30 V AC / 42.4 V DC
- Operating temperature: -20°C to +60°C
- Bending radius, min., repeated: 50 mm
- Bending radius, min., once: 25 mm
- Color sequence wires - wire pairs: White - blue, white - orange, white - green, white - brown
- Overall shield: Shielding braid made of copper wires
- Speed: 10 GBit/s
- Insulation diameter 1.04 mm
- Capacity at 1 kHz: 46 nF/km.
- Contact surface: AU ≥ 0.8 µm
- Coupling attenuation up to 1000 MHz: 80 dB
- Coupling resistance at 10 MHz: 5 mΩ/m.
- Copper diameter 0.43 mm
- Strands: 7
- Sheath diameter, max. 5.9 mm
- Net weight 230 g
- Shielding damping up to 1000 MHz: 60 dB
- Current carrying capacity at 50 °C: 1 A.
- Test voltage wire-wire shield 750 V DC, 1 min.
- Material sheath: LSZH
- Product type
Network cable, patch cable
CAT 6A
S/FTP
- Connection type
RJ45
- No. of A connectors
1 x
- Type A
RJ45 plug
- No. of B connections
1 x
- Type B
RJ45 plug
- Cable length
6.00 m
- Factory colour
Grey
- Connector version
straight
- Cable features
UL-approved
27/7
- Cable use
Networks
- Version
Cable
- Cable design
Round
Copper
- Max. frequency
500 MHz
- LAN transfer rate
100 MBit/s
1000 MBit/s
2500 MBit/s
10000 MBit/s
- Halogen-free
Yes
- Design type
S/UTP
S/FTP
6 m
Grey
IP20
Documents & Downloads
Datasheet
Datasheet 201094 Weidmüller 1165940060 RJ45 Network cable, patch cable CAT 6A S/FTP 6.00 m Grey UL-approved 1 pc(s)
User & Safety Instructions
User & Safety Instructions 201094 Weidmüller 1165940060 RJ45 Network cable, patch cable CAT 6A S/FTP 6.00 m Grey UL-approved 1 pc(s)
Description
The RJ45-Cable Fast Cat 5e offers more volume than the standard CAT5e cable and is perfect for use in 5 to 10 Base-T Networks and Giga bite Ethernet in the area. Delivery includes RJ45 plug (plug to plug) and the moulded strain relief.
Features
- Braided shield to the total cable
Hints
The term S/UTP conforms to the old STP standard.
