Weidmüller 1224490000 Plug inset 9 Soldering 1 pc(s)
EAN:
Part number:
Item no:
Product type
Plug inset
Connection
Soldering
Total no. of pins
9
Number of pins
9
Content
1 pc(s)
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 10.08
3
6% = € 0.58
€ 9.50
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 10.08 / piece)
€ 10.08
plus VAT.
Only 5 Piece(s) available
Technical specifications
- Net weight: 8 g
- Insulation resistance:> 1010 Ω
- Contact surface: Gold-plated
- Nominal current: 8 A / 1 mm + 20 A / 2 mm
- Plug-in cycles:> 1000
- Operating temperature, max.: 125 °C
- Operating temperature, min.: -40 °C
- Contact material: Copper-zinc alloy
- Connection thread: M23
- Fire behavior: V-0
- Housing base material: Thermoplastic polyamide PA 6, PBT
- number of contacts / diameter: 8 x 1 mm + 1 x 2 mm
- Product type
Plug inset
- Connection
Soldering
- Total no. of pins
9
- Number of pins
9
- Content
1 pc(s)
200 V
9
Pin
-40-125 °C
V0
Soldering connection
Gold
3
FALSE
Polyamide (PA)
Brass
8 A
Other
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1774754 Weidmüller 1224490000 Plug inset 9 Soldering 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1774754 Weidmüller 1224490000 Plug inset 9 Soldering 1 pc(s)
Description
Contact insert for circular connectors to be installed in a housing.
