Weidmüller 1474620000 Test terminal 6 mm Screws Grey 50 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Test terminal
Connection
Screws
Cross section (flexible) (max.)
4 mm²
Cross section (inflexible) (max.)
6 mm²
Datasheet (PDF)
Highlights & Details
Measuring separate terminal
- WTR 4 GR
Our service for you
Technical specifications
- Packaging type
Piece
- Product type
Test terminal
- Features
with screw connection
- Connection
Screws
- Cross section (flexible) (min.)
0.5 mm²
- Cross section (flexible) (max.)
4 mm²
- Cross section (inflexible) (min.)
0.5 mm²
- Cross section (inflexible) (max.)
6 mm²
- AWG (min.)
10
- AWG max.
22
- Clamp width
6 mm
- No. of rows
1
- Factory colour
Grey
- Nominal current
32 A
- Nominal current - rounded value
32 A
- Nominal voltage
400 V
- Stripping length (max.)
13 mm
- Manufacturer part #
1474620000
- Content
50 pc(s)
- Type
WTR 4 GR
- Dim
(L x W x H) 60 x 6 x 6.1 mm
- Width
6 mm
- Height
6.1 mm
- Length
60 mm
- RoHS-compliant
Yes
- Weight
11.554 g
- Flammability rating
UL 94 V0
- Connector colour
Grey
- Insulation material
Plastic
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1913354 Weidmüller 1474620000 Test terminal 6 mm Screws Grey 50 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 1913354 Weidmüller 1474620000 Test terminal 6 mm Screws Grey 50 pc(s) Piece
Description
The checks racing series terminal is used for isolation of circuits for test and measurement purposes.
