Small black torch with metal head and knurled handle, lying horizontally on a white surface.

Product type

Sensor/actuator connector

Connector type

Socket, straight

Connector standard

SAI Weidmüller

Connection side A

M8 socket, straight

Connection side B

Customisable

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Sensor/Actuator plug connector socket

SAIB-M 8-4 P

Technical specifications

Packaging type: Piece

Type: SAIB-M8-4P

Product type: Sensor/actuator connector

Connector type: Socket, straight

Connector standard: SAI Weidmüller

Connection side A: M8 socket, straight

Connection side B: Customisable

No. of pins: 4

Nominal voltage: 30 V

Nominal current: 4 A

Nominal current - rounded value: 4 A

Connection: Screw terminal

Thread type connection side: M8

Thread type (wiring and installation): M8

: IP67

Min. temperature: -25 °C

Max. temperature: +85 °C

Seal type: Screw-on

Manufacturer part #: 1803880000

Content: 1 pc(s)

RoHS-compliant: Yes

: Gland nut

: 60 V

: FALSE

: Bus

: Plastic

: Plastic-coated

: Screw connection

: Gold

: 3

: Straight

: 0.14-0.14 mm²

: 0.14-0.5 mm²

: IP67

: 4 A

UKCA: yes

Variants(All information is without VAT, plus shipping costs)

Type

Connector standard

Nominal current - rounded value

Connection side A

Connector type

No. of pins

Nominal voltage

Thread type connection side

Weidmüller 1803880000 Sensor/actuator connector M8 Socket, straight No. of pins (RJ): 4 1 pc(s) Piece

Item no:203817

This article

SAIB-M8-4P

SAI Weidmüller

4 A

M8 socket, straight

Socket, straight

30 V

Sockets prefabricated to customer spec., Plugs prefabricated to customer spec., M12, pin, 90°

Item no:195699

SAISW-3/7

4 A

M12 plug, right angle

Plug, right angle

250 V

M12

Sockets prefabricated to customer spec., Plugs prefabricated to customer spec., M12, pin, 90°

Item no:195700

SAISW-3/9

4 A

M12 plug, right angle

Plug, right angle

250 V

M12

Sockets prefabricated to customer spec., Plugs prefabricated to customer spec., M12, bush, 90°

Item no:195701

SAIBW-3/7

4 A

M12 socket, right angle

Socket, right angle

250 V

M12

Sockets prefabricated to customer spec., Plugs prefabricated to customer spec., M12, bush, 90°

Item no:195702

SAIBW-3/9

4 A

M12 socket, right angle

Socket, right angle

250 V

M12

Sockets prefabricated to customer spec., Plugs prefabricated to customer spec., M12, pin, straight

Item no:195707

SAIS-3/7

4 A

M12 plug, straight

Plug, straight

250 V

M12

Sockets prefabricated to customer spec., Plugs prefabricated to customer spec., M12, Female socket, straight

Item no:195709

SAIB-3/7

4 A

M12 socket, straight

Socket, straight

250 V

M12

Sockets prefabricated to customer spec., Plugs prefabricated to customer spec., M12, Female socket, straight

Item no:195710

SAIB-3/9

4 A

M12 socket, straight

Socket, straight

250 V

M12

Weidmüller 1044700000 Sensor/actuator connector M12 Plug, straight No. of pins (RJ): 5 1 pc(s) Piece

Item no:195952

SAIS-5/9-ZF

Sensor connector

4 A

M12 plug, straight

Plug, straight

125 V

M12

Weidmüller 1044710000 Sensor/actuator connector M12 Socket, straight No. of pins (RJ): 5 1 pc(s) Piece

Item no:195953

SAIB-5/9-ZF

Sensor connector

4 A

M12 socket, straight

Socket, straight

125 V

M12

Documents & Downloads

Datasheet

Datasheet 203817 Weidmüller 1803880000 Sensor/actuator connector M8 Socket, straight No. of pins (RJ): 4 1 pc(s) Piece

User & Safety Instructions

User & Safety Instructions 203817 Weidmüller 1803880000 Sensor/actuator connector M8 Socket, straight No. of pins (RJ): 4 1 pc(s) Piece

Description

Sensor/Actuator plug connector socket. M8 socket, straight. Often in today's world, individual cable lengths are required. In order to meet this requirement, Weidmüller offers a broad portfolio of connectors for free assembly. Plugs and sockets for free packing for M8, M12, M16 and 7/8" connectors are very robust and, for example, for mechanical engineering. The M8 circular connector are particularly suitable for applications with limited space. The screw connection is characterised by its versatile usability. With this technology, the conductor, optionally with wire-end sleeves, wire-in connection elements and connected by a screw fixed. It is the classical and most cost-effective connection technology, which also makes it possible to multi-conductor connections.
