Weidmüller 1827000000 Serial continuity Pull spring Orange 100 pc(s)
EAN:
Part number:
Item no:
Product type
Serial continuity
Connection
Pull spring
Cross section (flexible) (max.)
1.5 mm²
Cross section (inflexible) (max.)
1.5 mm²
Content
100 pc(s)
Datasheet (PDF)
Highlights & Details
Continuity series terminal
Our service for you
Technical specifications
- Product type
Serial continuity
- Features
+ test option
- Connection
Pull spring
- Cross section (flexible) (min.)
0.5 mm²
- Cross section (flexible) (max.)
1.5 mm²
- Cross section (inflexible) (min.)
0.5 mm²
- Cross section (inflexible) (max.)
1.5 mm²
- Factory colour
Orange
- Manufacturer part #
1827000000
- Content
100 pc(s)
- Industrial packaging
Yes
- Type
ZDU 1.5/2X2AN OR
- Dim
(L x W x H) 75.5 x 3.5 x 36.5 mm
- Width
3.5 mm
- Height
36.5 mm
- Length
75.5 mm
- RoHS-compliant
Yes
- Weight
6.99 g
- Connector colour
Orange
- Type
ZDU 1.5/2 X2 ON OR
Documents & Downloads
Datasheet
Datasheet 359383 Weidmüller 1827000000 Serial continuity Pull spring Orange 100 pc(s)
User & Safety Instructions
User & Safety Instructions 359383 Weidmüller 1827000000 Serial continuity Pull spring Orange 100 pc(s)
Description
Continuity series terminal. Z-Series terminal with spring-cage connection, nominal cross-section: 1.5 mm², Receptacle Wemid, orange, direct mounting. Terminal blocks in spring technology, the Z-series, are specifically tailored to customer requirements: Low available space, Spacious marking surfaces, integrated test point, cross-connectivity within the Z-series and to other Weidmüller terminal block ranges. The Z-series terminals have a large clamping range and up to two cross-connection channels. With standard plug-in cross-connectors, potentials can be distributed over any number of terminals.
