Weidmüller 1830650000 Serial continuity Pull spring Black 25 pc(s)
EAN:
Part number:
Item no:
Product type
Serial continuity
Connection
Pull spring
Cross section (flexible) (max.)
16 mm²
Cross section (inflexible) (max.)
16 mm²
Content
25 pc(s)
Datasheet (PDF)
Highlights & Details
Continuity series terminal
- ZDU 16 SW
Our service for you
Technical specifications
- Product type
Serial continuity
- Connection
Pull spring
- Cross section (flexible) (min.)
1.5 mm²
- Cross section (flexible) (max.)
16 mm²
- Cross section (inflexible) (min.)
1.5 mm²
- Cross section (inflexible) (max.)
16 mm²
- Factory colour
Black
- Manufacturer part #
1830650000
- Content
25 pc(s)
- Industrial packaging
Yes
- Type
ZDU 16 SW
- Dim
(L x W x H) 82.5 x 12.1 x 50.5 mm
- Width
12.1 mm
- Height
50.5 mm
- Length
82.5 mm
- RoHS-compliant
Yes
- Weight
39.08 g
- Connector colour
Black
- Type
ZDU16 BLACK
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 359503 Weidmüller 1830650000 Serial continuity Pull spring Black 25 pc(s)
User & Safety Instructions
User & Safety Instructions 359503 Weidmüller 1830650000 Serial continuity Pull spring Black 25 pc(s)
Description
Continuity series terminal. Z-Series terminal with spring-cage connection, nominal cross-section: 16 mm², spring-cage connection
