Weidmüller 1833690000 Dual port continuity 5.1 mm Screws Dark beige 50 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Dual port continuity
Connection
Screws
Cross section (flexible) (max.)
4 mm²
Cross section (inflexible) (max.)
4 mm²
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 7.38 / piece)
€ 368.91
plus VAT.
14-day return policy included
Highlights & Details
Double-level terminal block
- WDK 2.5/MOV
Our service for you
Technical specifications
- Packaging type
Piece
- Product type
Dual port continuity
- Connection
Screws
- Cross section (flexible) (min.)
0.5 mm²
- Cross section (flexible) (max.)
4 mm²
- Cross section (inflexible) (min.)
0.5 mm²
- Cross section (inflexible) (max.)
4 mm²
- AWG (min.)
30
- AWG max.
12
- Clamp width
5.1 mm
- No. of rows
2
- Pins per row
2
- Number of pins
4
- Factory colour
Dark beige
- Nominal current
20 A
- Nominal current - rounded value
20 A
- Nominal voltage
300 V
- Stripping length (max.)
10 mm
- Manufacturer part #
1833690000
- Content
50 pc(s)
- Industrial packaging
Yes
- Type
WDK 2.5/MOV
- Dim
(L x W x H) 62.5 x 5.1 x 69 mm
- Width
5.1 mm
- Height
69 mm
- Length
62.5 mm
- RoHS-compliant
Yes
- Flammability rating
V0
- Connector colour
Dark beige
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1694492 Weidmüller 1833690000 Dual port continuity 5.1 mm Screws Dark beige 50 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 1694492 Weidmüller 1833690000 Dual port continuity 5.1 mm Screws Dark beige 50 pc(s) Piece
Description
Terminal block for the installation of electronic components.
