Weidmüller 1953010000 Spring-loaded terminal 2.5 mm² Number of pins 2 Orange 100 pc(s)
EAN:
Part number:
Item no:
Product type
Spring-loaded terminal
CS
7.5 mm
Pins per row
2
Number of pins
2
Connection
Spring-loaded terminal
Print
Datasheet (PDF)
Highlights & Details
Spring-loaded terminal
- Content 100 pc(s)
Our service for you
Technical specifications
- Type
LMZFL 7/2/135 3.5OR
- Product type
Spring-loaded terminal
- CS
7.5 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Series
LMZF
- Min. stripping length
6 mm
- Stripping length (max.)
6 mm
- Connection
Spring-loaded terminal
Print
- Nominal current
15 A
- Cross section (flexible) (min.)
0.13 mm²
- Nominal current - rounded value
15 A
- Cross section (inflexible) (min.)
0.13 mm²
- Cross section (flexible) (max.)
2.5 mm²
- Cross section (inflexible) (max.)
2.5 mm²
- AWG (min.)
26
- Connector orientation
At an angle (to the PCB)
- AWG max.
14
- Contact material
Cu-alloy, tin plated
- Factory colour
Orange
- Wire protection
Yes
- Weight
3.39 g
- Manufacturer part #
1953010000
- Industrial packaging
Yes
- Content
100 pc(s)
- Nominal voltage
300 V
- Width
135 mm
- Height
230 mm
- Length
50 mm
- Type
7/2/135 3.5OR LMZFL
- UKCA
not relevant
