Buy Weidmüller 2001800000 DC/DC converter 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

A silver DC/DC converter device with an orange front panel. Inscription: 'Weidmüller', output voltage 24V/5A, adjustable between 23-28V.

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

DC DC Converters

Technical specifications

Storage temperature: -40 °C to +85 °C.
Inrush current: Max. 10 A.
Rise time< 9 ms
Number of terminals: 8 (+ / - / signal)
Tightening torque 0.4 Nm - 0.5 Nm
Housing design: Metal, corrosion-resistant

Type: DC/DC CONVERTER, 24 V

Nominal input voltage: 24 V/DC

Type: DC DC Converters

Product type: DC/DC converter

Min. input voltage: 14 V DC

Output voltage: 24 V DC

Input voltage: 14 - 32 V DC

Input voltage (max.): 32 V DC

Max. output current: 5 A

Output current (max.) - rounded: 5 A

: 120 W

Output voltage (nominal): 24 V DC

No. of outputs: 1 x

Connection: Push-fit screw connector

Dim: (L x W x H) 120 x 32 x 130 mm

Weight: 774 g

Output voltage (max.): 29.5 V DC

Output voltage (min.): 22.5 V DC

Operating temperature (max.): +70 °C

Max. operating temperature (derating): +70 °C

Min. operating temperature (derating): -25 °C

Operating temperature (min.): -25 °C

Manufacturer part #: 2001800000

Content: 1 pc(s)

MTBF: 1250000 h

PSU features: DC-to-DC converter

Width: 32 mm

Height: 130 mm

Length: 120 mm

: IP20

Max. temperature: +70 °C

Min. temperature: -25 °C

Type: PRO DCDC 120W 24V 5A

Efficiency: 92 %

: 32

: 130 mm

: 120 mm

: 230 mm

: 130.4 W

: 92 mm

: FALSE

: FALSE

: DC

: Screw connection

: TRUE

: IP20

: None

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1951535 Weidmüller 2001800000 DC/DC converter 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

User & Safety Instructions

User & Safety Instructions 1951535 Weidmüller 2001800000 DC/DC converter 24 V DC 5 A 120 W No. of outputs:1 x Content 1 pc(s)

Description

The compact DC/DC converter ensures the systems optimally against failures for maximum availability.
· Balancing voltage fluctuations
· Regeneration of the output voltage for a stable voltage at the end long lines
· Construction of erdfreier supply systems through galvanic isolation
· Above-average performance data
