Weidmüller 2423340000 Sensor/actuator built-in connector M8 Plug, vertical mount No. of pins (RJ): 8 25 pc(s)
EAN:
Part number:
Item no:
Product type
Sensor/actuator built-in connector
Connector type
Plug, vertical mount
Connector standard
SAI Weidmüller
Connection side A
M8 plug, built-in
Connection side B
Customisable
Datasheet (PDF)
Sales and shipping:
Total (€ 301.68 / piece)
€
Technical specifications
- Type
SAIE-M8B-8S-F13THR
- Product type
Sensor/actuator built-in connector
- Connector type
Plug, vertical mount
- Connector standard
SAI Weidmüller
- Connection side A
M8 plug, built-in
- Connection side B
Customisable
- No. of pins
8
- Nominal voltage
30 V
- Nominal current
1.50 A
- Nominal current - rounded value
1.5 A
- Connection
Print
- Factory colour
Silver
- Thread type connection side
M8
- Coding
B
- Contact material
CuZn
IP67
- Min. temperature
-30 °C
- Max. temperature
+80 °C
- Seal type
Screw-on
- Manufacturer part #
2423340000
- Content
25 pc(s)
- RoHS-compliant
Yes
Documents & Downloads
Datasheet
Datasheet 1514307 Weidmüller 2423340000 Sensor/actuator built-in connector M8 Plug, vertical mount No. of pins (RJ): 8 25 pc(s)
