Image similar
1/3
Image similar
Weidmüller 2466900000 SMPSU 24 V DC 40 A 960 W Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 684.87 / piece)
€ 684.87
plus VAT.
Only 5 Piece(s) available
Highlights & Details
Switched-mode power supply PROtop 1-phase
- 960 W power output
- Temperature range -40 to +85 °C.
Technical specifications
- Storage temperature: -40 °C to +85 °C.
- Inrush current: Max. 15 A.
- Frequency range AC 45 Hz - 65 Hz
- Surge protection input: Varistor
- Rise time< 100 ms
- Number of terminals: 5 (+ + / - - -)
- Housing design: Metal, corrosion-resistant
- Type
Power supply, switched-mode power supply, 24 V.
- Nominal input voltage
100-240 V/AC
120 - 340 V/DC
- Product type
SMPSU
- Min. input voltage
85 V AC
80 V DC
- Output voltage
24 V DC
- Input voltage
85 - 277 V/AC, 80 - 410 V DC
- Input voltage (max.)
410 V DC
277 V AC
- Max. output current
40 A
- Output current (max.) - rounded
40 A
960 W
- Phases
1
- Output voltage (nominal)
24 V DC
- Connection
Push-in connector
- Dim
(L x W x H) 125 x 124 x 130 mm
- Weight
3400 g
- Output voltage (max.)
28.8 V DC
- Output voltage (min.)
22.5 V DC
- Operating temperature (max.)
+70 °C
- Max. operating temperature (derating)
+70 °C
- Min. operating temperature (derating)
-25 °C
- Operating temperature (min.)
-25 °C
- Manufacturer part #
2466900000
- Content
1 pc(s)
- MTBF
1000000 h
- Width
124 mm
- Height
130 mm
- Length
125 mm
IP20
- Max. temperature
+70 °C
- Min. temperature
-25 °C
- Type
PRO TOP1 960W 24V 40A
- Efficiency
94 %
124
130 mm
125 mm
1021 W
FALSE
FALSE
AC/DC
Spring clamp connection
TRUE
IP20
None
None
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1661561 Weidmüller 2466900000 SMPSU 24 V DC 40 A 960 W Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1661561 Weidmüller 2466900000 SMPSU 24 V DC 40 A 960 W Content 1 pc(s)
Description
High-end power supplies must also work efficiently and reliably in harsh industrial environments. To do this, high power reserves, long life and optimal protection against overvoltages, vibrations and extreme temperature conditions. The new DCL technology gives PROtop superior dynamic range. This can be either for reliable tripping of circuit breakers or also for powerful motor starts.
