Weidmüller 2519550000 KLIPPON BDX M20 S with seal M20 M20 Stainless steel 1 pc(s)
EAN:
Part number:
Item no:
Internal thread
M20
External thread
M20
Material
Stainless steel
Features
with seal
Outside Ø
26.2 mm
Highlights & Details
Our service for you
Technical specifications
- Thread pitch: 1.5 mm
- impact strength: 7 J ATEX version
- Protection class with GWDR: IP66
- Head diameter: 26.2 mm
- Air throughput: 0.25 l/1 h
- O-ring: Silicone
- Seal: Silicone
- Tightening torque: 10 Nm
- Torque nozzle, max.: 10 Nm
- Torque counter nut, max.: 10 Nm
- Features
with seal
- Outside Ø
26.2 mm
- Internal thread
M20
- External thread
M20
- Spanner size
27 mm
- Thread length
10 mm
- Length
22 mm
- Width
27 mm
IP66
- Min. temperature
-60 °C
- Max. temperature
+200 °C
- Material
Stainless steel
- Content
1 pc(s)
- Dim
(L x W) 22 mm x 27 mm
- RoHS-compliant
Yes
- Weight
60 g
- Manufacturer part #
2519550000
- Type
KLIPPON BDX M20 S
- UKCA
not relevant
