Image similar
Image similar
Weidmüller 2651330000 Screw terminal 2.5 mm² Number of pins 2 Green 200 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Screw terminal
CS
5.08 mm
Pins per row
2
Number of pins
2
Highlights & Details
Our service for you
Technical specifications
- PCB angle/conductor connection 0°/180° (horizontal)Length of pin 3 mmNumber of floors: 1Dimensioning surge voltage: 4 kVOperating temperature: -40 °C - +105 °COvervoltage category IIPollution level: 2Flammability class of the insulating material according to UL 94: V0
- Packaging type
Piece
- Type
TMS 5.08/02/90 3.0SN GN BX
- Product type
Screw terminal
- CS
5.08 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Stripping length (max.)
6 mm
- Connection
Screws
Soldering
THT
- Nominal current
15 A
- Cross section (flexible) (min.)
0.2 mm²
- Nominal current - rounded value
15 A
- Cross section (inflexible) (min.)
0.2 mm²
- Cross section (flexible) (max.)
2.5 mm²
- Cross section (inflexible) (max.)
2.5 mm²
- AWG (min.)
30
- Connector orientation
Parallel (to the PCB)
- AWG max.
12
- Contact material
Cu-alloy, tin plated
- Enclosure material
Polyamide
- Factory colour
Green
- Manufacturer part #
2651330000
- Content
200 pc(s)
- Nominal voltage
300 V
- UKCA
not relevant
