Weidmüller 2651710000 PCB terminal 4 mm² Number of pins 2 Green 1 pc(s) Box
EAN:
Part number:
Item no:
Packaging type
Box
Product type
PCB terminal
CS
5 mm
Number of pins
2
Connection
Soldering
Datasheet (PDF)
Highlights & Details
PCB terminal, 250 V, 15 A, pitch in mm: 5.00, 4 mm², number of pins: 2, bracket connection, THT solder connection, 90°,box
- Content 1 pc(s)
Technical specifications
- Packaging type
Box
- Type
TPS 5.00/02/90 3.5SN GN BX
- Product type
PCB terminal
- CS
5 mm
- Number of pins
2
- Connection
Soldering
- Nominal current
15 A
- Cross section (flexible) (min.)
0.2 mm²
- Nominal current - rounded value
15 A
- Cross section (inflexible) (min.)
0.2 mm²
- Cross section (flexible) (max.)
4 mm²
- Cross section (inflexible) (max.)
4 mm²
- Connector orientation
Parallel (to the PCB)
- Enclosure material
Polyamide
- Factory colour
Green
- Manufacturer part #
2651710000
- Content
1 pc(s)
- Nominal voltage
250 V
- Type
TPS 5.00/02/90 3.5SN GN BX
Green
250 V
-40-105 °C
Solder
2.5 kV
6021
II
2
Screw connection
Soldering connection
3.5 mm
5 mm
Other
0.2-4 mm²
0.2-2.5 mm²
0.2-4 mm²
Polyamide (PA)
0°/180° (horizontal)
Other
2
V0
Documents & Downloads
Datasheet
Datasheet 3767655 Weidmüller 2651710000 PCB terminal 4 mm² Number of pins 2 Green 1 pc(s) Box
User & Safety Instructions
User & Safety Instructions 3767655 Weidmüller 2651710000 PCB terminal 4 mm² Number of pins 2 Green 1 pc(s) Box
Description
PCB terminal (PCB terminal, circuit board terminal) for secure, simple data transfer directly to the PCB.
