The image shows a grey flat ribbon cable with a black connector at one end and two connected black connectors at the other end.

Image similar

The image shows a grey flat ribbon cable with a black connector at one end and two connected black connectors at the other end.

Image similar

Weidmüller

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Technical specifications

Net weight: 1,998 g
Storage temperature, max.: 60 °C
Storage temperature, min.: -10 °C
Connection SPS: Rockwell CONTROL LOGIX 1756-TBCH 36P
Connection Interface: Flat CABLE CONTTOR HE10 20P
Number of poles, min.: 20 Pole
Outer diameter: 8.6 ± 1 mm
Cable: LiYY
Material: PVC
conductor cross-section: 0.25 mm²
Permissible current per path, max.: 1 A
total current, max. 3 A
resistance: ≤ 80 mΩ/m
High voltage test: 1 KV/1s

Product type: PLC cable

Operating voltage: 60, 25 V DC, V AC (max)

Max. operating voltage: 60 V DC
25 V AC

Length: 9 m

Manufacturer part #: 7789042090

Type: PAC-CTLX-HE20-V3-9M

Max. ambient temperature: +50 °C

Min. ambient temperature: -10 °C

UKCA: yes
