Weidmüller 7906170000 Terminal Screws Medium yellow 25 pc(s)
EAN:
Part number:
Item no:
Product type
Terminal
Connection
Screws
Cross section (flexible) (max.)
2.5 mm²
Cross section (inflexible) (max.)
4 mm²
Content
25 pc(s)
Datasheet (PDF)
Highlights & Details
Multi-pin terminal strip
Our service for you
Technical specifications
- Product type
Terminal
- Features
with screw connection
- Connection
Screws
- Cross section (flexible) (min.)
0.5 mm²
- Cross section (flexible) (max.)
2.5 mm²
- Cross section (inflexible) (min.)
0.5 mm²
- Cross section (inflexible) (max.)
4 mm²
- Factory colour
Medium yellow
- Manufacturer part #
7906170000
- Content
25 pc(s)
- Industrial packaging
Yes
- Type
MK 3/8/E
- Dim
(L x W x H) 72.75 x 15 x 16.1 mm
- Width
15 mm
- Height
16.1 mm
- Length
72.75 mm
- RoHS-compliant
Yes
- Weight
31.64 g
- Insulation material
Polyamide
- Type
MK3/8/E
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 391095 Weidmüller 7906170000 Terminal Screws Medium yellow 25 pc(s)
User & Safety Instructions
User & Safety Instructions 391095 Weidmüller 7906170000 Terminal Screws Medium yellow 25 pc(s)
Description
Multi-pin terminal strip. Rated cross-section: 2.5 mm², screw connection, direct mounting. Multi-pin terminal strips are established at Weidmüller for many years. The terminal blocks can be screwed directly on the housing a re-tighten the clamp screw by setting the conductor even in these terminals is not required. The terminal blocks are in the Materials KRG and PA and with different connection techniques available.
