Image similar
Image similar
Weidmüller ACT20P-CI-2CO-OLP-P 2619390000 Isolation amplifier 1 pc(s)
EAN:
Part number:
Item no:
Product type
Isolation amplifier
Input signal (current) (max.)
20 mA
Type
ACT20P-CI-2CO-OLP-P
Dim
(L x W x H) 114 x 12.5 x 127.1 mm
Connection
Spring-loaded connector
Technical specifications
- Type
ACT20P-CI-2CO-OLP-P
- Product type
Isolation amplifier
- Input signal (current) (max.)
20 mA
- Dim
(L x W x H) 114 x 12.5 x 127.1 mm
- Connection
Spring-loaded connector
- Output (current)
4 - 20 mA
- Operating voltage
300 V (max)
- Max. operating voltage
300 V
- Input signal (current)
4-20 mA
- Content
1 pc(s)
- Configuration
not adjustable
- Width
12.5 mm
- Height
127.1 mm
- Length
114 mm
- RoHS-compliant
Yes
- Max. ambient temperature
+60 °C
- Min. ambient temperature
-20 °C
- Supply voltage (num.)
30 V DC
- Cross section (inflexible) (max.)
2.5 mm²
- Cross section (inflexible) (min.)
0.5 mm²
- UKCA
yes
