Weidmüller ACT20P-VMR-3PH-ILP-H-P 7760054361 Limit switch 1 pc(s)
EAN:
Part number:
Item no:
Product type
Limit switch
Input signal (voltage) (max.)
500
Type
ACT20P-VMR-3PH-ILP-H-P
Dim
(L x W x H) 114.3 x 22.5 x 117 mm
Connection
Push-in connector
Technical specifications
- Type
ACT20P-VMR-3PH-ILP-H-P
- Product type
Limit switch
- Input signal (voltage) (max.)
500
- Dim
(L x W x H) 114.3 x 22.5 x 117 mm
- Connection
Push-in connector
- Operating voltage
600 V AC (max)
- Max. operating voltage
600 V AC
- Input signal (voltage)
Spannung 3-phasig
- Content
1 pc(s)
- Configuration
DIP switch
Potentiometer
- Width
22.5 mm
- Height
117 mm
- Length
114.3 mm
- RoHS-compliant
Yes
- Max. ambient temperature
+60 °C
- Min. ambient temperature
-25 °C
- Supply voltage (num.)
180 V AC
- Cross section (inflexible) (max.)
2.5 mm²
- Cross section (inflexible) (min.)
0.5 mm²
- UKCA
yes
