Weidmüller CLI C 2-6 GE/SW PE CD Ring Imprint PE Outside diameter range 4 up to 10 mm 1871901731
EAN:
Part number:
Item no:
Product type
Ring
Imprint
PE
Suitable for outside Ø (min.)
4 mm
Suitable for outside Ø (max.)
10 mm
Dim
(L x W x H) 8 x 7 x 6 mm
Datasheet (PDF)
Highlights & Details
Lead marker cable line ® CLI C
- No. of markers: 125
- Imprint: PE
Technical specifications
- Net weight: 0.349 g
- Printing color: Black
- Printing method: Hot embossed
- Material color according to resistance code: 4
- Orientation of imprint: Horizontal
- Insulation diameter, max.: 10 mm
- conductor cross-section, max.: 16 mm²
- conductor cross-section, min.: 2.5 mm²
- Product type
Ring
- Dim
(L x W x H) 8 x 7 x 6 mm
- Imprint
PE
- Type
Special characters
- Series
CableLine® CLI C
- Factory colour
Yellow
- Material
PVC
- Suitable for outside Ø (min.)
4 mm
- Suitable for outside Ø (max.)
10 mm
- Min. temperature
-30 °C
- Max. temperature
+80 °C
- Features
UL94 flammability rating
halogen-free
- No. of markers
125
- Outside diameter range
4 up to 10 mm
- Colour-coded
Yes
- Halogen-free
Yes
- Manufacturer part #
1871901731
- Industrial packaging
Yes
- Content
125 pc(s)
- Width
7 mm
- Height
6 mm
- Length
8 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 362729 Weidmüller CLI C 2-6 GE/SW PE CD Ring Imprint PE Outside diameter range 4 up to 10 mm 1871901731
User & Safety Instructions
User & Safety Instructions 362729 Weidmüller CLI C 2-6 GE/SW PE CD Ring Imprint PE Outside diameter range 4 up to 10 mm 1871901731
Description
Lead marker. 6 x 7 mm, PVC, soft, without cadmium, color: yellow. CLI C-lead marker are not connected conductor mounted. Conductor cross-sections of 0,5mm² up to a maximum of 70 mm² can be with four different sizes. The markers are printed. Closed marker, safe and adjusted to non-connected lines. Wide area of use by means of a special bellows profile with spring effect. Fast, easy mounting with a flick of the wrist. The corresponding accessories facilitates the marker work. Permanent marking of high quality. Best contrasts for optimum readability.
This text is machine translated.
This text is machine translated.
Scope of delivery
- roller
