Weidmüller CLI C 3-9 GE/SW L2 MP Ring Imprint L2 Outside diameter range 8 up to 16 mm 0253511729
EAN:
Part number:
Item no:
Product type
Ring
Imprint
L2
Suitable for outside Ø (min.)
8 mm
Suitable for outside Ø (max.)
16 mm
Dim
(L x W x H) 17 x 11 x 9 mm
Datasheet (PDF)
Highlights & Details
Lead marker cable line ® CLI C
- No. of markers: 20
- Imprint: L2
Our service for you
Technical specifications
- Net weight: 1.05 g
- Printing color: Black
- Printing method: Hot embossed
- Material color according to resistance code: 4
- Orientation of the imprint: Horizontal
- Insulation diameter, max.: 16 mm
- conductor cross-section, max.: 70 mm²
- conductor cross-section, min.: 16 mm²
- Product type
Ring
- Dim
(L x W x H) 17 x 11 x 9 mm
- Imprint
L2
- Type
Letters
Numbers
- Series
CableLine® CLI C
- Factory colour
Yellow
- Material
PVC
- Suitable for outside Ø (min.)
8 mm
- Suitable for outside Ø (max.)
16 mm
- Min. temperature
-30 °C
- Max. temperature
+80 °C
- Features
UL94 flammability rating
halogen-free
- No. of markers
20
- Outside diameter range
8 up to 16 mm
- Colour-coded
Yes
- Halogen-free
Yes
- Manufacturer part #
0253511729
- Industrial packaging
Yes
- Content
20 pc(s)
- Width
11 mm
- Height
9 mm
- Length
17 mm
- Dimensions
9 x 11 mm
- Features
Printable
- Fitting type
Slide-on
- Series
CLI C
- Writing area length
9 mm
- Writing area width
11 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 277547 Weidmüller CLI C 3-9 GE/SW L2 MP Ring Imprint L2 Outside diameter range 8 up to 16 mm 0253511729
User & Safety Instructions
User & Safety Instructions 277547 Weidmüller CLI C 3-9 GE/SW L2 MP Ring Imprint L2 Outside diameter range 8 up to 16 mm 0253511729
Description
Lead marker. 9 x 11 mm, PVC, soft, without cadmium, color: yellow. CLI C-lead marker are not connected conductor mounted. Conductor cross-sections of 0.5 mm² up to a maximum of 70 mm² can be with four different sizes. The markers are printed. Closed marker, safe and adjusted to non-connected lines. Wide area of use by means of a special bellows profile with spring effect. Fast, easy mounting with a flick of the wrist. Permanent marking of high quality. Best contrasts for optimum readability.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Multi-Pack
