Weidmüller Continuity 1 pc(s) MOS SUPPLY 300 V (max) IP20
EAN:
Part number:
Item no:
Product type
Continuity
Connection
Screw terminal
Max. operating voltage
300 V
Type
MOS SUPPLY
Operating voltage
300 V (max)
Datasheet (PDF)
Technical specifications
- Storage temperature: -40 °C to +80 °C.
- Mounting rail TS 35
- Colour, black
- Surge voltage 4 kV (1.2/50 µs)
- Wire stripping length rated connection 7 mm
- Clamping range, rated connection 2.5 mm²
- Clamping range 0.5 mm² - 4 mm²
- Conductor cross-section, fine strand 0.5 mm² - 2.5 mm²
- Blade dimensions 0.6 mm x 3.5 mm
- Product type
Continuity
- Type
MOS SUPPLY
- Connection
Screw terminal
- Max. operating voltage
300 V
- Operating voltage
300 V (max)
IP20
- Min. temperature
-25 °C
- Max. temperature
+60 °C
- Width
6.1 mm
- Height
88.1 mm
- Length
97.8 mm
- Dim
(L x W x H) 97.8 x 6.1 x 88.1 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 258874 Weidmüller Continuity 1 pc(s) MOS SUPPLY 300 V (max) IP20
User & Safety Instructions
User & Safety Instructions 258874 Weidmüller Continuity 1 pc(s) MOS SUPPLY 300 V (max) IP20
Description
Continuity series terminal. Micro opto, accessories, screw connection. In the series MICRO OPTO the user can fall back on features of the series terminals. Plug-in cross connections and end-to-end marking solutions with minimum width. Largest performance even in the smallest room. 6.1 mm width. Standard plug-in cross connection ZQV 4 N. Labeling with multi-card system is possible. Snap-on mounting rails TS 35. Housing Material WEMID (with a higher temperature capacity compared to polyamide).
