Weidmüller CRI20730 Mini industrial relay Nominal voltage: 230 V AC Switching current (max.): 8 A 2 change-overs 10 pc(s
EAN:
Part number:
Item no:
Product type
Mini industrial relay
Contact type
2 change-overs
Nominal voltage
230 V AC
Switching voltage (max.)
250 V AC
250 V DC
Switching current (max.)
8 A
Datasheet (PDF)
Technical specifications
- Product type
Mini industrial relay
- Type
CRI20730
- Connection
Jack connector
- Contact type
2 change-overs
- Contact material
AgNi
- Nominal voltage
230 V AC
- Switching voltage (max.)
250 V AC
250 V DC
- Switching current (max.)
8 A
- Features
w/o test button
IP40
Relay protection type RT II
- Length
15.7 mm
- Width
12.7 mm
- Dim
(L x W) 15.7 mm x 12.7 mm
- Content
10 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3750995 Weidmüller CRI20730 Mini industrial relay Nominal voltage: 230 V AC Switching current (max.): 8 A 2 change-overs 10 pc(s
User & Safety Instructions
User & Safety Instructions 3750995 Weidmüller CRI20730 Mini industrial relay Nominal voltage: 230 V AC Switching current (max.): 8 A 2 change-overs 10 pc(s
Description
Relay for switching, amplifying and reproducing digital signals when using low electrical loads. Small design
