Weidmüller DRM270024LT AU Plug-in relay 24 V DC 10 A 2 change-overs 20 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Plug-in relay
Coil nominal voltage
24 V DC
Contact type
2 change-overs
Switching voltage (max.)
250 V AC
Datasheet (PDF)
Technical specifications
- Relay small structural dimensions for switching, reinforce and duplication of digital signals of less electrical loads.
- Packaging type
Piece
- Product type
Plug-in relay
- Type
DRM270024LT AU
- Coil nominal voltage
24 V DC
- Min. pick-up voltage
18 V DC
- Max. pick-up voltage
31.2 V DC
- Resistance (coil)
650 Ω
- Contact type
2 change-overs
- Contact material
AgNi
- Switching voltage (max.)
250 V AC
- Switching current (max.)
10 A
- Max. switching capacity
2500 VA
240 W
- Creepage distance (coil/clips)
5.5 mm
- Connection
Jack connector
- Fall time
20 ms
- Durability
20 x 106 Switches
- Features
+ test button
IP20
- Min. temperature
-40 °C
- Max. temperature
+55 °C
- Weight
35 g
- Factory colour
Transparent
- Width
21 mm
- Height
27.4 mm
- Depth
35.7 mm
- Dim
(W x H x D) 21 x 27.4 x 35.7 mm
- Industrial packaging
Yes
- Content
20 pc(s)
- RoHS-compliant
Yes
- Permanent current (max.)
10 A
- Operating voltage
24 V DC
- Switch-on current
20 A
- UKCA
not relevant
