Weidmüller HDC IP68 16B TOS 2M25 1082780000 Plug enclosure 1 pc(s)
EAN:
Part number:
Item no:
Product type
Plug enclosure
Thread size
M25
Case material
Aluminium, die cast
Type
HDC IP68 16B TOS 2M25
Series
RockStar® HDC IP68
Datasheet (PDF)
Highlights & Details
Connector housing
- HDC IP68 16B TOS 2 M 25
Technical specifications
- Height of housing B: 164 mm
- Length of housing: 110.5 mm
- Tightening torque: 6.5 Nm
- EMC Housing: Yes
- Surface: Powder coating
- Material Locking element: Stainless steel, stainless
- steel Number of cable input above: 2
- Number of cable input side: 0
- Design type: Standard
- size: 6
- Clip version: Screw cap
- suitable for ModulPlug®: Yes
- Size
- of cable inputs: M 25 Upper part/cover: Upper part
- Type
HDC IP68 16B TOS 2M25
- Product type
Plug enclosure
- Series
RockStar® HDC IP68
- Manufacturer part #
1082780000
- Features
2x cable entry (straight)
+ thread
- Thread size
M25
- Case material
Aluminium, die cast
- Factory colour
Black
- Weight
576 g
- Content
1 pc(s)
- Width
58 mm
- Height
110.5 mm
IP68
IP69K
- Max. temperature
+125 °C
- Min. temperature
-50 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 199736 Weidmüller HDC IP68 16B TOS 2M25 1082780000 Plug enclosure 1 pc(s)
User & Safety Instructions
User & Safety Instructions 199736 Weidmüller HDC IP68 16B TOS 2M25 1082780000 Plug enclosure 1 pc(s)
Description
Connector housing. HDC-casing, size: 6, protection class IP68, connector housing, screw cap, Standard, large cable inputs: M25. The new seawater-resistant and highly impact-resistant rock star-housing in IP68 and IP69K are developed for use under extreme environmental conditions and for the high vibration requirements according to the DIN EN 61373 CAT2 (bogie). Thus, this family of cases well suited for interference-free and maintenance-free operation of heavy plug connectors in the transport and traffic technology as well as in the energy technology and in applications with extreme requirements.
