Buy Weidmüller HTF 28 9013090000 Crimper F plugs/sockets 0.1 up to 1 mm²

An orange crimping pliers with black handles is shown, suitable for crimping electrical connections.

A red and black crimping pliers with an ergonomic handle, used for processing cable lugs or connectors.

1/2

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Technical specifications

Crimp type/profile: B-Crimp
connector width 2.8 mm

Product type: Crimper

Manufacturer part #: 9013090000

Range of uses: F plugs/sockets

Suitable for: 2.8 mm width

Crimp area: 0.1 up to 1 mm²

Crimp area AWG: 18 up to 28 awg

Crimp area (min.): 0.1 mm²

Crimp area (max.): 1 mm²

Crimp area AWG (min.): 28 awg

Crimp area AWG (max.): 18 awg

Length: 200 mm

Width: 200 mm

Height: 282 mm

Weight: 449.98 g

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 259133 Weidmüller HTF 28 9013090000 Crimper F plugs/sockets 0.1 up to 1 mm²

User & Safety Instructions

User & Safety Instructions 259133 Weidmüller HTF 28 9013090000 Crimper F plugs/sockets 0.1 up to 1 mm²

Description

Crimping tool for contacts. 0.1 mm², 1 mm², B-crimp. Inseparable: a unique combination. Weidmüller crimp tools combine decades of experience in the contact technology with the competence in the area of professional tools. The standard features of the HTF-crimp tools for RSV system are available for maximum contact security with simple operation: integrated forced lock. Safety release, precise positioning stop. The built-in functions guarantee a standard-compliant crimp geometry by exact positioning and automatic 100% compression. The result: 100% Crimp Result = 100% failure safety.
