Weidmüller MCZ PT100/3 CLP 0...120C 8483680000 Temperature transducer 10 pc(s)
EAN:
Part number:
Item no:
Product type
Temperature transducer
Type
MCZ PT100/3 CLP 0...120C
Dim
(L x W) 91 mm x 6 mm
Connection
Pull spring
Output (current)
4 mA-20 mA
Datasheet (PDF)
Technical specifications
- Depth: 63.2 mm
- Net weight 30 g
- Operating temperature 25 °C - 55 °C
- Storage temperature: -25 °C to +85 °C.
- Number of inputs: 1
- Sensor: Pt100/2-/3-wire
- Number of outputs: 1
- Galvanic isolation: Between input/output
- Accuracy: type. 0.2%, max. 0.5% of FSR
- Mounting rail TS 35
- Jump response time: 10 ms
- Sensor supply: 0.8 mA / 9 V/DC-30 V/DC
- Conductor cross-section AWG, min. AWG 26
- Conductor cross-section AWG, max. AWG 16
- Type
MCZ PT100/3 CLP 0...120C
- Product type
Temperature transducer
- Dim
(L x W) 91 mm x 6 mm
- Connection
Pull spring
- Output (current)
4 mA-20 mA
- Operating voltage
50 V (max)
- Max. operating voltage
50 V
- Load
600 Ω
- Content
10 pc(s)
- Width
6 mm
- Length
91 mm
- RoHS-compliant
Yes
- Type
PT100
- Max. ambient temperature
50 °C
- Min. ambient temperature
-25 °C
- Supply voltage (num.)
30 V
- Cross section (flexible) (max.)
1.5 mm²
- Cross section (flexible) (min.)
0.5 mm²
- Depth
63.2 mm
- Industrial packaging
Yes
- Type
MCZ PT 100/3 CLP 0...120C
- Weight
30 g
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 391361 Weidmüller MCZ PT100/3 CLP 0...120C 8483680000 Temperature transducer 10 pc(s)
User & Safety Instructions
User & Safety Instructions 391361 Weidmüller MCZ PT100/3 CLP 0...120C 8483680000 Temperature transducer 10 pc(s)
Description
RTD-converter. MCZ SERIES. Output current loop powered PT100 Signal Converter MCZ PT 100/3 in 6 mm wide series terminal housing. CLP . The Signal converters are designed for a specific temperature range for the connection of 2- and 3-wire PT100 sensors. On the output side, there is a current loop gespeistes 4 … 20 mA signal are available. Input and output circuit derMCZ PT 100/3 CLPsind not electrically isolated. The signal converter can be mounted on mounting rails TS 35 and are characterized by high accuracy and linearity.
