Weidmüller Pin housing cable BC/SC Total number of pins 5 Contact spacing: 3.81 mm 2444100000 50 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 3.19 / piece)
€
Highlights & Details
- Content: 50 pc(s)
- No. of rows: 1
- Total number of pins: 5
Technical specifications
- Connector system
wire-to-board
- Series
BC/SC
- Features
encodable
- CS
3.81 mm
- Pins per row
5
- Total number of pins
5
- Nominal current
17.50 A
- Nominal current - rounded value
17.5 A
- Content
50 pc(s)
- Factory colour
Orange
- Industrial packaging
Yes
- Connection
Pull spring
- Connector orientation
Perpendicular (to the PCB)
- Manufacturer part #
2444100000
- Type
SCZ 3.81/05/180LR SN OR BX
- Nominal voltage
320 V
- AWG max.
16
- AWG (min.)
28
- max. cross section
1.50 mm²
- Stripping length (max.)
7 mm
- No. of rows
1
- Min. cross section
0.20 mm²
- Case material
PA GF
- RoHS-compliant
Yes
- Max. temperature
+120 °C
- Min. temperature
-50 °C
- Product type
Pin housing cable
