Weidmüller Plug-in module + LED, + varistor RIM 4 24/60VUC GN Colours (LEDs): Green Piece 10 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Plug-in module
Max. operating voltage
60 V DC/AC
Case colour
Black
Colour
Green
Datasheet (PDF)
Highlights & Details
Plug-in module RIM 4
Our service for you
Technical specifications
- Storage temperature: -40 °C…70 °C
- Conductor connection technology: Plug connection
- Packaging type
Piece
- Product type
Plug-in module
- Features
+ LED
+ varistor
- Type
RIM 4 24/60VUC GN
- Content
10 pc(s)
- Min. operating voltage
24 V DC/AC
- Max. operating voltage
60 V DC/AC
- Operating voltage
24 - 60 V DC/AC
- Case colour
Black
- Colour
Green
- Compatible with
Weidmüller
- Compatible with series
Weidmüller RIDERS RCL series
- Min. temperature
-40 °C
- Max. temperature
+70 °C
- Width
12.5 mm
- Height
9 mm
- Length
34.5 mm
- Dim
(L x W x H) 34.5 x 12.5 x 9 mm
- Industrial packaging
Yes
- Weight
3 g
- RoHS-compliant
Yes
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 391664 Weidmüller Plug-in module + LED, + varistor RIM 4 24/60VUC GN Colours (LEDs): Green Piece 10 pc(s)
User & Safety Instructions
User & Safety Instructions 391664 Weidmüller Plug-in module + LED, + varistor RIM 4 24/60VUC GN Colours (LEDs): Green Piece 10 pc(s)
Description
The plug-in LED module for the RIDERS RCL series relay socket.
