Weidmüller RCL424012T Plug-in relay 12 V DC 8 A 2 change-overs 20 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Plug-in relay
Coil nominal voltage
12 V DC
Contact type
2 change-overs
Switching voltage (max.)
440 V AC
Datasheet (PDF)
Technical specifications
- Relay small structural dimensions for switching, reinforce and duplication of digital signals of less electrical loads.
- Packaging type
Piece
- Product type
Plug-in relay
- Type
RCL424012T
- Coil nominal voltage
12 V DC
- Min. pick-up voltage
8.4 V DC
- Resistance (coil)
360 Ω
- Contact type
2 change-overs
- Contact material
AgNi 90/10
- Switching voltage (max.)
440 V AC
- Switching current (max.)
8 A
- Max. switching capacity
2000 VA
192 W
- Creepage distance (coil/clips)
10 mm
- Connection
Jack connector
- Fall time
6 ms
- Durability
30 x 106 circuits
- Features
w/o LED
IP40
- Min. temperature
-40 °C
- Max. temperature
+70 °C
- Weight
13.3 g
- Factory colour
Transparent
- Width
12.7 mm
- Height
29 mm
- Depth
15.7 mm
- Dim
(W x H x D) 12.7 x 29 x 15.7 mm
- Industrial packaging
Yes
- Content
20 pc(s)
- RoHS-compliant
Yes
- Permanent current (max.)
8 A
- Operating voltage
12 V DC
- Switch-on current
15 A
- UKCA
not relevant
