Weidmüller Relay card equipped 1 pc(s) RSM-8 C 1CO S 1 change-over 250 V AC Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Relay card
Operating voltage
250 V AC
Contact type
1 change-over
Connection
Screws
Datasheet (PDF)
Technical specifications
- Packaging type
Piece
- Product type
Relay card
- Features
equipped
- Type
RSM-8 C 1CO S
- Operating voltage
250 V AC
- Channels
8
- Contact type
1 change-over
- Switching voltage (max.)
24 V DC
- Switching current (max.)
5 A
- Connection
Screws
- Content
1 pc(s)
- Weight
416 g
- Max. temperature
+50 °C
- Min. temperature
-25 °C
- Length
110 mm
- Width
109 mm
- Height
68 mm
- Dim
(L x W x H) 110 x 109 x 68 mm
- RoHS-compliant
Yes
DIN rail (top hat rail) 35 mm
110
109 mm
68 mm
250 V
20
Screw connection
2
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 259619 Weidmüller Relay card equipped 1 pc(s) RSM-8 C 1CO S 1 change-over 250 V AC Piece
User & Safety Instructions
User & Safety Instructions 259619 Weidmüller Relay card equipped 1 pc(s) RSM-8 C 1CO S 1 change-over 250 V AC Piece
Description
Transfer module. Interface, RSM, 8 compact, RCL, screw connection. Digital output interface per relay for the electrical signal transmission between the PLC and the field. Electrical insulation by use of a pluggable relay. Integrated LED status indicator.
