Weidmüller SCM 2CO Relay socket + LED Compatible with series: Weidmüller RIDERS series (L x W x H) 80 x 27 x 77 mm 10 pc
EAN:
Part number:
Item no:
Product type
Relay socket
Connection
Screws
Mounting type
DIN rail
Content
10 pc(s)
Features
+ LED
Datasheet (PDF)
Highlights & Details
Relay Sockets
Our service for you
Technical specifications
- Tightening torque, max.: 0.8 Nm
- Continuous current 12 A
- Clamping range, rated connection 2.5 mm²
- Clamping range, max. 2.5 mm²
- Storage temperature: -40 °C…70 °C
- Nominal switching voltage 250 V AC
- Standards: UL508
- Switching capacity AC (ohmic), max. 3000 VA
- Switching voltage AC, max. 300 V
- Voltage strength input - output: 2.5 kVeff / 1 min.
- Depth: 61.5 mm
- Product type
Relay socket
- Content
10 pc(s)
- Features
+ LED
- Factory colour
Black
- Connection
Screws
- Mounting type
DIN rail
- Contact type
2 change-overs
- Industrial packaging
Yes
- Weight
57.42 g
- Compatible with
Weidmüller
- Compatible with series
Weidmüller RIDERS series
IP20
- Min. temperature
-45 °C
- Max. temperature
+70 °C
- Width
27 mm
- Height
77 mm
- Length
80 mm
- Dim
(L x W x H) 80 x 27 x 77 mm
- RoHS-compliant
Yes
- Type
SCM 2CO
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 391588 Weidmüller SCM 2CO Relay socket + LED Compatible with series: Weidmüller RIDERS series (L x W x H) 80 x 27 x 77 mm 10 pc
User & Safety Instructions
User & Safety Instructions 391588 Weidmüller SCM 2CO Relay socket + LED Compatible with series: Weidmüller RIDERS series (L x W x H) 80 x 27 x 77 mm 10 pc
Description
Relay socket. RIDERSERIES, accessories. Is the ideal relay variant for the industrial automation to separate input and output signals. With the RIDERS series can be safely switched high performance. Standard relay and LED indicators are simply plugged, holding and dismantling bracket to hold it securely.
