Weidmüller Socket housing cable BL Total number of pins 12 Contact spacing: 3.5 mm 1531100000 36 pc(s)
EAN:
Part number:
Item no:
Product type
Socket housing cable
Connector type
Connector, straight
No. of rows
1
Series
BL
CS
3.5 mm
Datasheet (PDF)
Number (Package size 36 pc(s))
Total (€ 6.89 / piece)
€ 247.90
plus VAT.
Highlights & Details
- Content: 36 pc(s)
- No. of rows: 1
- Total number of pins: 12
Our service for you
Technical specifications
- Product type
Socket housing cable
- Connector type
Connector, straight
- No. of rows
1
- Connector system
wire-to-board
- Series
BL
- Features
+ latch
- CS
3.5 mm
- Pins per row
12
- Total number of pins
12
- Nominal current
10 A
- Nominal current - rounded value
10 A
- Content
36 pc(s)
- AWG max.
14
- AWG (min.)
28
- Stripping length (max.)
6 mm
- Connection angle
180°
- Case material
PBT
- Manufacturer part #
1531100000
- Factory colour
Orange
- Contact material
Copper alloy
- Connector contact surface
Tin plated
- Nominal voltage
300 V
- max. cross section
1.5 mm²
- Min. cross section
0.08 mm²
- RoHS-compliant
Yes
- Max. temperature
+100 °C
- Min. temperature
-30 °C
- Type
BL 3.50/12/180LR SN OR BX
- UKCA
not relevant
