Weidmüller SSR 2618600000 Switching voltage (max.): 48 V DC 10 pc(s)
EAN:
Part number:
Item no:
Product type
SSR
Control voltage (min.)
12 V DC
Control voltage (max.)
12 V DC
Switching voltage (max.)
48 V DC
Output voltage (max.)
48 V DC
Technical specifications
- Humidity: 5...95 % rel. humidity. TU = 40 °C. No condensation
- Storage temperature: -40 °C - +70 °C on/off voltage: 4.9 V / 4
- V/DC Status display: LED green
- Protective circuit: Rectifier
- Coil voltage Spare relay: 5 V/DC
- Switch-on delay: 0.4 ms
- Switch-off delay: 3 ms<
- Voltage drop at max. load: <<1 V
- leakage current< 10 µA
- min. Switching current: 500 µA
- short-circuit proof: No
- Protection circuit Load side: Snubber diode
- Mounting rail: TS 35
- Color: Black
- flammability class according to UL 94: V-0
- Rated voltage: 300 V
- Pollution degree: 2
- Overvoltage category: III
- Standing surge voltage: 6 kV (1.2/50 µs)
- Stripping length Rated connection: 8 mm
- Clamping range, rated connection: 1.5 mm²
- Clamping
- mm²
- range, min.: 0.14 mm² Clamping range, max.: 2.5 AWG. AWG 26
- conductor cross-section AWG, max.: AWG 14
- conductor cross-section, single-wire min.: 0.14 mm²
- conductor cross-section, single-wire max.: 2.5 mm²
- conductor cross-section, fine-wire min.: 0.14 mm²
- conductor cross-section, fine-wire max.: 2.5 mm²
- conductor cross-section, fine-wire min. (AWG): AWG 26
- conductor cross-section, fine-wired. Max. (AWG): AWG 14
- blade dimension: 0.4 x 2.0 mm
- on/off current: 0.5 mA / 0.23 mA DC
- max. switching frequency (DC control voltage): 10 Hz
- Product type
SSR
- Type
TOP 12VDC 48VDC0.1A
- Connection
Push-in button
- Control voltage (min.)
12 V DC
- Control voltage (max.)
12 V DC
- Control voltage range
12 - 12 V DC
- Control current (max.)
5 mA
- Switching voltage (min.)
0 V DC
- Switching voltage (max.)
48 V DC
- Max. switching capacity
112 mW
- Output voltage (min.)
3 V
- Output voltage (max.)
48 V DC
- Max. output current
0.1 A
- Contact type
1 maker
- Min. temperature
-20 °C
- Max. temperature
+60 °C
IP20
- Width
6.4 mm
- Height
89.4 mm
- Depth
87.8 mm
- Weight
29 g
- Permanent current (max.)
0.1 A
- Content
10 pc(s)
- Nominal control voltage
12 V DC
- UKCA
not relevant
