Weidmüller SSR 4061180000 0.1 A Switching voltage (max.): 48 V DC 20 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
SSR
Control voltage (min.)
18 V DC
Control voltage (max.)
30 V DC
Switching voltage (max.)
48 V DC
Datasheet (PDF)
Highlights & Details
Solid state relays
- Industrial packaging with 20 pieces
Technical specifications
- Storage temperature, max. 70 °C.
- Storage temperature, min.: -40 °C
- Status indicator: No.
- Switch-on delay < 35 µs
- Switch-off delay < 355 µs
- Voltage drop at max. load: ≤ 1 V.
- Leakage current < 10 µA
- Short-circuit proof: No.
- Colour, black
- Creepage and air distance control side - load side: ≥ 5.5 mm
- Humidity: 40 °C / 93 % rel. humidity, no condensation
- MTTF: 4,298 Years
- min Switching current 500 µA
- Protective circuit on load side: Snubber diode
- Electrical strength, control side - load side: 2.5 kVeff
- Packaging type
Piece
- Product type
SSR
- Type
SSS RELAIS 24V/24V 0,1ADC
- Connection
Jack connector
- Control voltage (min.)
18 V DC
- Control voltage (max.)
30 V DC
- Control voltage range
18 - 30 V DC
- Control current (max.)
7 mA
- Switching voltage (min.)
0 V DC
- Switching voltage (max.)
48 V DC
- Current load (max.)
0.1 A
- Max. switching capacity
170 mW
- Output voltage (min.)
3 V DC
- Output voltage (max.)
48 V DC
- Max. output current
100 mA
- Contact type
1 maker
- Min. temperature
-20 °C
- Max. temperature
+60 °C
- Width
5 mm
- Height
28 mm
- Depth
15 mm
- Weight
3.53 g
- Industrial packaging
Yes
- Permanent current (max.)
0.1 A
- Content
20 pc(s)
- Nominal control voltage
24 V DC
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 390961 Weidmüller SSR 4061180000 0.1 A Switching voltage (max.): 48 V DC 20 pc(s)
User & Safety Instructions
User & Safety Instructions 390961 Weidmüller SSR 4061180000 0.1 A Switching voltage (max.): 48 V DC 20 pc(s)
Description
Solid state relays. Nominal control voltage 18V DC...24V DC...30V DC, nominal switching voltage: 3...48 V DC, nominal switching current: 100mA DC, plug connection
