Weidmüller SSR 8576360000 4 A Switching voltage (max.): 275 V AC 15 pc(s)
EAN:
Part number:
Item no:
Packaging type
Package
Product type
SSR
Control voltage (min.)
15 V DC
15 V AC
Control voltage (max.)
30 V DC
30 V AC
Switching voltage (max.)
275 V AC
Datasheet (PDF)
Highlights & Details
Solid state relays
- Industrial packaging with 15 pieces
Technical specifications
- Storage temperature, max. 50 °C.
- Storage temperature, min.: -40 °C
- Status indicator: No.
- Switch-on delay: ≤ 12 ms
- Switch-off delay 20 ms
- Voltage drop at max. load: ≤ 1.1 V.
- Leakage current < 1 mA
- Short-circuit proof: No.
- Color: Light blue
- Rated voltage: 300 V
- Over voltage category III
- Creepage and air distance control side - load side: > 8 mm
- Surge voltage 4 kV (1.2/50 µs)
- Packaging type
Package
- Product type
SSR
- Type
SSR 24V ACDC/230VAC 4A
- Connection
Jack connector
- Control voltage (min.)
15 V DC
15 V AC
- Control voltage (max.)
30 V DC
30 V AC
- Control voltage range
15, 15 - 30, 30 V DC, V AC
- Control current (max.)
10 mA
- Switching voltage (min.)
12 V AC
- Switching voltage (max.)
275 V AC
- Current load (max.)
4 A
- Max. switching capacity
240 mW
- Output voltage (min.)
12 V
- Output voltage (max.)
275 V AC
- Max. output current
4 A
- Contact type
1 maker
- Min. temperature
-40 °C
- Max. temperature
+50 °C
- Width
13 mm
- Height
29.2 mm
- Depth
25 mm
- Weight
18.467 g
- Industrial packaging
Yes
- Permanent current (max.)
4 A
- Content
15 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 391423 Weidmüller SSR 8576360000 4 A Switching voltage (max.): 275 V AC 15 pc(s)
User & Safety Instructions
User & Safety Instructions 391423 Weidmüller SSR 8576360000 4 A Switching voltage (max.): 275 V AC 15 pc(s)
Description
Solid state relays. Nominal control voltage: 15 V UC...30 V UC, nominal switching voltage: 12...275 V AC, nominal switching current: 4 A, plug connection. The Modular Modular system represents a new generation of pluggable opto-couplers. Core is an innovative relay socket PXS or PXZ. The plug series, an ideal link between SSR and application, is especially easy to service. Standard SSR and LED indicators are simply plugged, holding and dismantling bracket to hold it securely. Pre-assembled SSR-coupler complete the delivery program. Plug-in cross connection bridges ZQV 2.5 enable fast installation of multiple couplers by simple and straightforward.
