Weidmüller SSR 8820710000 0.25 A Switching voltage (max.): 137.5 V DC 10 pc(s)
EAN:
Part number:
Item no:
Packaging type
Package
Product type
SSR
Control voltage (min.)
24 V DC
Control voltage (max.)
110 V DC
Switching voltage (max.)
137.5 V DC
Datasheet (PDF)
Highlights & Details
Solid state relays
- Industrial packaging, pack of 10
Technical specifications
- Storage temperature, max. 85 °C.
- Storage temperature, min.: -40 °C
- Status indicator: Green LED
- Switch-on delay: ≤ 10 ms
- Switch-off delay: ≤ 50 ms
- Voltage drop at max. load: ≤ 1.7 V.
- Short-circuit proof: No.
- Color: beige
- Rated voltage: 300 V
- Over voltage category III
- Creepage and air distance control side - load side: ≥ 5.5 mm
- Surge voltage 6 kV (1.2/50 µs)
- Humidity: 95% for 30 days, slight condensation according to EN 50155
- MTTF: 1,943 years
- On/off voltage 14 V/13.5 V DC
- Protection circuit: Reverse polarity protection
- Protective circuit on load side: Varistor, snubber diode
- Mounting rail TS 35
- Flammability class according to UL 94: V-0
- Pollution level: 2
- Electrical strength control side - load side: 1 kVeff / 1 s.
- Wire stripping length rated connection: 8 mm
- Clamping range, rated connection 1.5 mm²
- Clamping range, min. 0.5 mm²
- Clamping range, max. 1.5 mm²
- Conductor cross-section AWG, min. AWG 26
- Conductor cross-section AWG, max. AWG 16
- Conductor cross-section, single-wire, min.: 0.5 mm²
- Conductor cross-section, single-wire, max. 1.5 mm²
- Conductor cross-section, fine strand, min. 0.5 mm²
- Conductor cross-section, fine strand, max. 1.5 mm²
- Conductor cross-section, fine strand, min. (AWG) AWG 26
- Conductor cross-section, fine strand, max. (AWG): AWG 16
- Conductor cross-section, fine strand AEH with plastic collar DIN 46228/4, min.: 0.5 mm²
- Conductor cross-section, fine strand AEH with plastic collar DIN 46228/4, max. 1.5 mm²
- Conductor cross-section, fine strand, AEH (DIN 46228-1), min. 0.5 mm²
- Conductor cross-section, fine strand, AEH (DIN 46228-1), max. 1.5 mm²
- Blade size 0.6 x 3.5 mm
- Max. Switching frequency (DC control voltage): 10 Hz
- Packaging type
Package
- Product type
SSR
- Type
MCZ O TRAK 24.110VDC
- Connection
Pull spring
- Control voltage (min.)
24 V DC
- Control voltage (max.)
110 V DC
- Control voltage range
24 - 110 V DC
- Control current (max.)
2.8 mA
- Switching voltage (min.)
5 V DC
- Switching voltage (max.)
137.5 V DC
- Current load (max.)
0.25 A
- Output voltage (min.)
5 V DC
- Output voltage (max.)
137.5 V DC
- Max. output current
0.25 A
- Contact type
1 maker
- Min. temperature
-25 °C
- Max. temperature
+70 °C
IP20
- Width
6.1 mm
- Height
91 mm
- Depth
63.2 mm
- Weight
23.9 g
- Industrial packaging
Yes
- Permanent current (max.)
0.25 A
- Content
10 pc(s)
Documents & Downloads
Datasheet
Datasheet 391726 Weidmüller SSR 8820710000 0.25 A Switching voltage (max.): 137.5 V DC 10 pc(s)
User & Safety Instructions
User & Safety Instructions 391726 Weidmüller SSR 8820710000 0.25 A Switching voltage (max.): 137.5 V DC 10 pc(s)
Description
Solid state relays. MCZ-SERIES, nominal control voltage: 24...110 V DC -30/+25%, nominal switching voltage: 5...137.5 V DC, nominal switching current 180 mA, spring-cage connection. The that allows clamping conductor cross-section is 0.5 ... 1.5 mm².
