Image similar
Image similar
Weidmüller TRP 60VUC 1CO EMPTY Relay socket 60 V DC/AC 10 A 1 change-over 1 pc(s)
EAN:
Part number:
Item no:
Product type
Relay socket
Contact type
1 change-over
Nominal voltage
60 V DC/AC
Switching current (max.)
10 A
Type
TRP 60VUC 1CO EMPTY
Technical specifications
- Mounting rail TS 35
- Flammability class according to UL 94 V-0
- Over voltage category III
- Pollution level: 2
- Surge voltage 6 kV (1,2/50 µs)
- Stripping length: 8 mm
- Clamping range, rated connection: 1.5 mm²
- Clamping range, min.: 0.14 mm²
- Clamping range, max. 2.5 mm²
- Conductor cross section AWG min. 26
- Conductor cross section AWG, max. 14
- Wire cross-section, single-wire, min.: 0.14 mm²
- Wire cross-section, single-wire, max. 2.5 mm²
- Conductor connection cross-section, fine wire, min.: 0.14 mm²
- Conductor connection cross-section, fine wire, max. 2.5 mm²
- Blade dimensions 0.4 x 2.0 mm
- Product type
Relay socket
- Type
TRP 60VUC 1CO EMPTY
- Connection
Push-in button
- Factory colour
Black
- Contact type
1 change-over
- Nominal voltage
60 V DC/AC
- Switching current (max.)
10 A
- Features
+ LED display
IP20
- Max. temperature
+60 °C
- Min. temperature
-40 °C
- Depth
87.8 mm
- Width
6.4 mm
- Height
89.6 mm
- Dim
(W x H x D) 6.4 x 89.6 x 87.8 mm
- Content
1 pc(s)
- Weight
24.5 g
- UKCA
yes
