Weidmüller VP M25 EX SI 7J Seal inset Terminal Ø (max.) 25 mm Board thickness (max.) 9 mm Polyamide 6 Black 100 pc(s)
EAN:
Part number:
Item no:
Product type
Seal inset
Material
Polyamide 6
Clamp Ø
25 mm
Terminal Ø (max.)
25 mm
Mounting hole
M25
Datasheet (PDF)
Highlights & Details
Our service for you
Technical specifications
- Thread: M25
- thread length: 10 mm
- thread pitch: 1.5 mm
- O-ring: Silicone
- seal: Silicone
- torque nozzle: 2.5 Nm
- Torque nut: 2.3 Nm - 2.5 Nm
- Product type
Seal inset
- Factory colour
Black
- Material
Polyamide 6
- Length
15.8 mm
- Height
15.8 mm
- (Ø)
25 mm
- Dim
(Ø x H) 25 mm x 15.8 mm
- Clamp Ø
25 mm
- Terminal Ø (max.)
25 mm
- Mounting hole
M25
- Spanner size
28 mm
- Board thickness (max.)
9 mm
- Min. temperature
-60 °C
- Max. temperature
+70 °C
IP54
IP66
IP67
IP68
- Weight
5 g
- Halogen-free
Yes
- Content
100 pc(s)
- Manufacturer part #
2066740000
- Type
VP M25 EX SI 7J
- RoHS-compliant
Yes
- UKCA
not relevant
