Weiss Elektrotechnik 85/378 PCB mount transformer 1 x 230 V 2 x 12 V AC 10 VA 417 mA
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 15.12
3
5% = € 0.75
€ 14.37
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 15.12 / piece)
€ 15.12
plus VAT.
Highlights & Details
EI 48-Print transformator 10 VA
- 1 x 230 V
- 2 x 12 V AC
- 417 mA
- 10 VA
Technical specifications
- Pin arrangement Primary: PIN 1 - 6, Pin arrangement secondary 2: PIN 7 - 8 / 11 - 12
- Design UL 506
- Output voltage
12 V AC
- Output voltage (number x voltage)
2 x 12 V AC
- Output current
417 mA
- No. of inputs
1 x
- No. of outputs
2 x
- Input voltage
230 V
- Input voltage (number x voltage)
1 x 230 V
10 VA
- Width
43 mm
- Height
36 mm
- Length
51 mm
- Type
85/378
- Content
1 pc(s)
- Dim
(L x W x H) 51 x 43 x 36 mm
- Connection
Soldering
10 VA
- Output voltage
2 x 12 V
- Frequency
50 - 60 Hz
- Weight
285 g
- Product type
PCB mount transformer
