Wera 05078684001 Open-ended spanner socket bit 32 mm
EAN:
Part number:
Item no:
Number
Total (€ 45.37 / piece)
€ 45.37
plus VAT.
14-day return policy included
Highlights & Details
7783 E Plug-in tool with through-hole square, 14x18 mm, 14x18 x 3/4" x 70 mm
- For torque wrench in the Click-Torque X series with 14x18 mm holder
- With through-hole square with ball locking.
- With pin lock
- These plug-in tools are suitable for high loads owing to the design in chromium-vanadium steel
Technical specifications
- Material
Chromium-vanadium steel
- Spanner size
32 mm
- Downforce
Square, solid, 20 mm (3/4")
- Drive
Square socket bit 14 x 18 mm
- Size
32 mm
- Dim
(L x W x H) 120 x 120 x 41 mm
- Weight
410 g
- Content
1 pc(s)
- Material properties
matt chrome plating
- Product type
Open-ended spanner socket bit
- Width
120 mm
- Height
41 mm
- Length
120 mm
- Size
3/4"
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1668685 Wera 05078684001 Open-ended spanner socket bit 32 mm
Description
Application: For 3/4" square socket wrench inserts as well as 3/4" square drive connecting parts Drive: 14x18 mm; for torque wrench series Click-Torque X and XP with 14x18 mm holder Design: With through-hole square with ball locking, forged, chrome-vanadium steel, matt chrome-plated; with pin locking
This text is machine translated.
This text is machine translated.
Features
- Chromium-vanadium steel
- With pin lock.
