Buy Wera Kraftform Kompakt VDE 67 i TX 30 x 157 mm TIE Electrician TORX Interchangeable bit TX 30

Electric screwdriver with a red handle and green head. Markings: 'TE6/1' and 'TX 30' on the head.

A voltmeter shows a reading of 9 kV on a scale from 0 to 12. It is built into an electrical device.

A set of red and yellow screwdriver handles with interchangeable, insulated blades in various colours and sizes.

Various screwdrivers with red handles and interchangeable blades of different shapes and sizes, suitable for diverse screw-related tasks.

'Figure shows various screwdriver bits with their respective shapes and colours: Cross-Black, Star-Green, Hexagon-Yellow.'

Green USB stick with a red 'Root' text, positioned diagonally in a USB port, next to a red X symbol.

A hand grips a green pen, pointing upwards. The background is grey.

'VDE GS tested' seal and '1000 V' symbol on a black background. Text 'VDE TOOL'. Safety and voltage indication.

'TAKE IT EASY TOOL FINDER' in white text, above a stylised green and white tool representation on a black background.

1/9

Datasheet (PDF)

Unavailable

27 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Highlights & Details

Compact form VDE 67 i TORX® Take it easy, TX 30 x 157 mm

VDE Interchangeable blade for Torx screws TX 30x157

Technical specifications

Product type: Interchangeable bit

Range of use: Electrician

Downforce: TORX

Size: TX 30

Length: 157 mm

Height: 7 mm

Width: 7 mm

Weight: 34 g

Dim: (L x W x H) 157 x 7 x 7 mm

Documents & Downloads

Datasheet

Datasheet 3165505 Wera Kraftform Kompakt VDE 67 i TX 30 x 157 mm TIE Electrician TORX Interchangeable bit TX 30

User & Safety Instructions

User & Safety Instructions 3165505 Wera Kraftform Kompakt VDE 67 i TX 30 x 157 mm TIE Electrician TORX Interchangeable bit TX 30

Description

VDE blade for power form compact handle / replacement blade system. Lightning-fast replacement of the blade without special tools. Tested tools according to IEC 60900 Routine test at 10,000 V for safe working at the approved voltage of 1,000 V. The Wera black point tip offers fitting accuracy and optimized corrosion protection. With Tool Finder Take it easy: Colour marking according to profiles as well as lasered size specification. The hexagonal unroll protection prevents the blade from rolling away unintentionally.

This text is machine translated.

Features

Kraftform Compact VDE Interchangeable blade for TORX® screws
Insulated, piece-tested according to IEC 60900
9 mm hexagonal drive with guide edge
With Black Point tip for high corrosion protection and form-fitting
Take it easy tool finder: Colour codes by profile and lasered size specification

Scope of delivery

VDE Interchangeable blade for Torx screws TX 30x157
