Whadda WPM432 PCB design board 1 pc(s) Compatible with (development kits): Arduino
EAN:
Part number:
Item no:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 16.80
3
5% = € 0.83
€ 15.97
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 16.80 / piece)
€ 16.80
plus VAT.
Technical specifications
- Product type
PCB design board
- Compatible with
Arduino
- Interfaces
XLR plug
- Output voltage (max.)
2.5 V
- Output voltage (min.)
-2.5 V
- Suitable for
Arduino
- Tool type
Development kit
- Height
15.50 mm
- Width
7.80 mm
- No. of outputs
1 x
- Weight
42.0000
- Compatible with
Arduino
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2481909 Whadda WPM432 PCB design board 1 pc(s) Compatible with (development kits): Arduino
Description
With this Arduino add-on, you can use the Arduino as a DMX master device (transmitter). This board is a simple circuit based around a driver chip (MAX-485 or SN 75176) with an XLR-3-pin plug DMX output connector. Pin1 = Common signal, Pin2 = Data, Pin3 = Data +. The board converts the Arduino signal voltage according to DMX (RS485). Impedance is 100 Ohm.
This text is machine translated.
This text is machine translated.
