WIKA 32 Equipment glass thermometer -30 - 50 °C incl. immersion probe
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Type: W 3221, nominal size 200 x 36, model 90° angled
- Error limits: According to DIN 16 195
- V-shaped aluminum casing
- Housing color: Anodised brass color
- Unit: °C
- Display range: -30 °C ... +50 °C
- Process connection G 1/2 B
- Mounting length L1: 100 mm
- Dip-shank material: Cu alloy
- Screw-in pins,
- Submersible shaft diameter 10 mm
- Product type
Equipment glass thermometer
- Max. temperature
50 °C
Manufacturer's standards (no certificate)
- Features
incl. immersion probe
- Probe length
100 mm
- Calibration range
Temperature
- Length
100 mm
- Min. temperature
-30 °C
- Type
32
Documents & Downloads
Datasheet
Datasheet 3526414 WIKA 32 Equipment glass thermometer -30 - 50 °C incl. immersion probe
User & Safety Instructions
User & Safety Instructions 3526414 WIKA 32 Equipment glass thermometer -30 - 50 °C incl. immersion probe
Description
Machine glass thermometer
Technical data according to data sheet: TM 32.02
Error limits: According to DIN 16 195
V-shaped aluminum casing
Housing color: Anodised brass color
Type: W 3221, nominal size 200 x 36, model 90° angled
Screw-in pins,
Unit: °C
Display range: -30 °C ... +50 °C
Process connection G 1/2 B
Submersible shaft diameter 10 mm
Mounting length L1: 100 mm
Dip-shank material: Cu alloy
Manufacturer logo: *WIKA*
This text is machine translated.
