Name: WIKA 632.50 Pressure gauge Bottom 0 up to 250 mbar
Brand: WIKA
SKU: 3525781

A round pressure gauge displaying values from 0 to 100 mbar, with a needle pointing at 60. The gauge is labeled 'EN 837-1'.

Image similar

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Type 632.50
Case: CrNi steel
Unit: Mbar
Display range 0 mbar...250 mbar
Process connection G 1/2 B
Needle mechanism: CrNi steel
Measurement system CrNi steel
Nominal size 100 mm
Connection position: Below
Viewing glass: Multi-layered safety glass
Pressure gauge standard: International (Europe)
Housing filling: Without
Ring: Bayonet ring, CrNi steel
Scale color for 1.Division (outside): Black
Face background: White
IP 54 protection
Packaging: Individual packaging
Standard label on dial: *EN 837-3*
Accuracy class dial: *Cl.1.6*
Housing with ex-hole
Permissible ambient temperature: Standard
Case material: CrNi steel
Permissible temperature of the measured substance: Standard

Product type: Pressure gauge

Min. display range: 0 mbar

Display range (max.): 250 mbar

Manufacturer part #: 9803246

Material (details): CrNi steel

Dim: (Ø) 100 mm

Connection: G 1/2 B

Connector: Bottom

Max. operating pressure: 250 mbar

Operating pressure (min.): 0 mbar

Pressure range: 0 up to 250 mbar

(Ø): 100 mm

: IP54

Documents & Downloads

Datasheet

Datasheet 3525781 WIKA 632.50 Pressure gauge Bottom 0 up to 250 mbar

User & Safety Instructions

User & Safety Instructions 3525781 WIKA 632.50 Pressure gauge Bottom 0 up to 250 mbar

Description

Pressure gauge with capsule spring, chemical design
Type 632.50
Technical data according to data sheet PM 06.03
Measurement system CrNi steel
Case: CrNi steel
Ring: Bayonet ring, CrNi steel
Needle mechanism: CrNi steel
Housing filling: Without
Nominal size 100 mm
Unit: Mbar
Display range 0 mbar...250 mbar
Process connection G 1/2 B
Connection position: Below
Housing with ex-hole
IP 54 protection
Packaging: Individual packaging
Permissible ambient temperature: Standard
Permissible temperature of the measured substance: Standard
Case material: CrNi steel
Viewing glass: Multi-layered safety glass
Face labels
Pressure gauge standard: International (Europe)
Scale color for 1.Division (outside): Black
Face background: White
Manufacturer logo: *WIKA*
FORTLFD.-NO. *...*
Standard label on dial: *EN 837-3*
Accuracy class dial: *Cl.1.6*
Individual package labels: Standard (with Wika logo)
Labels Outer packaging: Standard (with Wika logo)

This text is machine translated.
