Name: WIKA Bourdon tube gauge 9022996 213.53 Connector (pressure gauge): Back side -1 up to 1.5 bar 1 pc(s)
Brand: WIKA
SKU: 3526902

WIKA Bourdon tube gauge 9022996 213.53 Connector (pressure gauge): Back side -1 up to 1.5 bar 1 pc(s)-0

Image similar

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Type 213.53-E
Casing: CrNi steel, crimp type
Display range: -1...+1.5 bar
Process connection G 1/2 B
Measuring system: Copper alloy
Nominal size 100 mm
Connection position: Eccentric at rear
Accuracy class: Class 1.0
Pressure gauge standard: International (Europe)
Serial number on dial: FORTLFD.-NR. *...*
Filling medium housing: Glycerin-water mixture

Product type: Bourdon tube gauge

Min. display range: -1 bar

Max. operating pressure: 1.5 bar

Display range (max.): +1.5 bar

Manufacturer part #: 9022996

Material (details): CrNi steel, crimp type

Dim: (Ø) 100 mm

Connection: G 1/2

Connector: Back side

Operating pressure (min.): -1 bar

Pressure range: -1 up to 1.5 bar

(Ø): 100 mm

Documents & Downloads

Datasheet

Datasheet 3526902 WIKA Bourdon tube gauge 9022996 213.53 Connector (pressure gauge): Back side -1 up to 1.5 bar 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3526902 WIKA Bourdon tube gauge 9022996 213.53 Connector (pressure gauge): Back side -1 up to 1.5 bar 1 pc(s)

Description

Pressure gauge with pipe spring, liquid filling,
CrNi steel casing, type 213.53.100
Type 213.53-E
Technical data according to data sheet PM 02.12
Measuring system: Copper alloy
Case:CrNi steel 1.4301
Casing: CrNi steel, crimp type
Nominal size 100 mm
Display range: -1...+1.5 bar
Process connection G 1/2 B
Connection position: Eccentric at rear
Accuracy class: Class 1.0
Filling medium housing: Glycerin-water mixture
Pressure gauge standard: International (Europe)
Manufacturer logo: *WIKA*
Serial number on dial: FORTLFD.-NR. *...*

This text is machine translated.
