Image similar
WIKA Bourdon tube gauge 9032061 332.30 Connector (pressure gauge): Bottom 0 up to 250 bar 1 pc(s)
Part number:
Item no:
Technical specifications
- Casing: CrNi steel, with break-proof partition and blow-out rear panel
- Display range 0...250 bar
- Process connection G 1/2 B
- Measurement system CrNi steel
- Nominal size 160 mm
- Measuring range: Pressure measuring range
- Connection position: Below
- Viewing glass: Multi-layered safety glass
- Accuracy class: Class 0.6
- Pressure gauge standard: International (Europe)
- Main scale unit: Bar
- Housing filling: Without
- Ring: Bayonet ring, CrNi steel
- Pointer: Cutting edge pointer
- Serial number: With serial number
- Material process connection: CrNi steel
- Material of measuring link: CrNi steel
- Overload protection 1.3-fold
- Fine measuring execution, safety design: 332.30
- Permissible ambient temperature: -40 … +60 °C.
- Permissible temperature with a temperature of + 200 °C.
- Product type
Bourdon tube gauge
- Min. display range
0 bar
- Max. operating pressure
250 bar
- Display range (max.)
250 bar
- Operating temperature
-40 up to 60 °C
- Min. operating temperature
-40 °C
- Max. operating temperature
60 °C
- Manufacturer part #
9032061
- Material (details)
CrNi steel, with break-proof partition and inflatable rear wall
- Dim
(Ø) 160 mm
- Connection
G 1/2
- Connector
Bottom
- Operating pressure (min.)
0 bar
- Pressure range
0 up to 250 bar
- (Ø)
160 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3525798 WIKA Bourdon tube gauge 9032061 332.30 Connector (pressure gauge): Bottom 0 up to 250 bar 1 pc(s)
Description
Pressure gauge with pipe spring, CrNi steel,
Fine measurement, safety design
Type 332.30
Technical data according to data sheet PM 03.05
Measurement system CrNi steel
Casing: CrNi steel, with break-proof partition and blow-out rear panel
Ring: Bayonet ring, CrNi steel
Housing filling: Without
Nominal size 160 mm
Main scale unit: Bar
Measuring range: Pressure measuring range
Display range 0...250 bar
Process connection G 1/2 B
Material process connection: CrNi steel
Material of measuring link: CrNi steel
Connection position: Below
Viewing glass: Multi-layered safety glass
Pointer: Cutting edge pointer
Accuracy class: Class 0.6
Overload protection 1.3-fold
Permissible ambient temperature: -40 … +60 °C.
Permissible temperature of measuring substance: + 200 °C.
With threaded protective cap
Pressure gauge standard: International (Europe)
Manufacturer logo: *WIKA*
Serial number: With serial number
QR code with extended serial number on dial
This text is machine translated.
Fine measurement, safety design
Type 332.30
Technical data according to data sheet PM 03.05
Measurement system CrNi steel
Casing: CrNi steel, with break-proof partition and blow-out rear panel
Ring: Bayonet ring, CrNi steel
Housing filling: Without
Nominal size 160 mm
Main scale unit: Bar
Measuring range: Pressure measuring range
Display range 0...250 bar
Process connection G 1/2 B
Material process connection: CrNi steel
Material of measuring link: CrNi steel
Connection position: Below
Viewing glass: Multi-layered safety glass
Pointer: Cutting edge pointer
Accuracy class: Class 0.6
Overload protection 1.3-fold
Permissible ambient temperature: -40 … +60 °C.
Permissible temperature of measuring substance: + 200 °C.
With threaded protective cap
Pressure gauge standard: International (Europe)
Manufacturer logo: *WIKA*
Serial number: With serial number
QR code with extended serial number on dial
This text is machine translated.
