WIKA Check valve 0717010 910.11 400 bar (max) 1 pc(s)
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Design: Fixed sleeve design
- Permissible nominal pressure: PN max. 400 bar
- Type of accessory 910.11-E
- Process/device connection: 1/2NPT stud + 1/2NPT sleeve
- Design: Without test connection, according to DIN 16270 or similar (with bleed screw)
- Material packing PTFE
- Material body: Stainless steel
- Permissible temperature for the test substance: -40...+200°C.
- Product type
Check valve
- Type
Without test connection, according to DIN 16270 or similar (with bleed screw)
- Operating temperature
-40 up to +200 °C
- Min. operating temperature
-40 °C
- Max. operating temperature
+200 °C
- Manufacturer part #
0717010
- Material (details)
Stainless steel
- Connection
1/2NPT tap + 1/2NPT sleeve
- Max. operating pressure
400 bar
- Pressure range
400 bar (max)
Documents & Downloads
Datasheet
Datasheet 3524836 WIKA Check valve 0717010 910.11 400 bar (max) 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3524836 WIKA Check valve 0717010 910.11 400 bar (max) 1 pc(s)
Description
DIN-stop valve Technical data according to data sheet: AC 09.02 Design: Without test connection, according to DIN 16270 or similar (with bleed screw)
